SATURN
Saturn Downlight 12W 4000K
Product Data
| Part Code (s) | R091802/105/4K |
| Applications | Interior |
| Warranty | 5 years |
| Certification(s) | CE, RoHS |
Physical Data
| Colour Finish | White |
| Dimensions (mm) | Ø105 x H82 |
| Luminaire Fixing | Recessed |
| Construction Material | Aluminium |
| Diffuser Type | TPa rated |
Electrical Data
| Wattage | 12W |
| Voltage Range | AC220-240 |
| Power Factor | >0.90 |
| Inrush Current | <60A |
| Running Current | DC350mA |
Dimension Diagram
ricoman.com
Product design and technical data may be subject to change.
0161 877 1399
sales@ricoman.com
Part Code: R091802/105/4K
Technical Data
| Lumens (±5%) | 1266 |
| Efficacy | ~105Lm/W |
| Operating Temperature | -20°C to +45°C |
| Beam Angle | 40° |
| Operating Hours | >50000 |
| IP Rating | IP20 |
| IK Rating | IK09 |
Light Source Data
| Kelvins | 4000K |
| CRI | >90Ra |
| Macadam Ellipse | Equal or less than 3 sdcm |
| L80 B50 | 90000 hours |
| LEDs | CREE COB |
Photometric Diagram
Image not available
ricoman.com
Product design and technical data may be subject to change.
0161 877 1399
sales@ricoman.com
