PINNACLE
Pinnacle 6W 38° Fixed Spotlight 3000K
Product Data
| Part Code (s) | R097701/38D |
| Applications | Interior |
| Warranty | 5 years |
| Certification(s) | CE, RoHS |
Physical Data
| Colour Finish | Titanium |
| Dimensions (mm) | Ø68 x H64mm |
| Luminaire Fixing | Recessed |
| Construction Material | Aluminium |
| Diffuser Type | PMMA |
Electrical Data
| Wattage | 6W |
| Voltage Range | AC220-240V |
| Power Factor | >0.90 |
| Inrush Current | 2A |
| Running Current | DC200mA |
Dimension Diagram
ricoman.com
Product design and technical data may be subject to change.
0161 877 1399
sales@ricoman.com
Part Code: R097701/38D
Technical Data
| Lumens (±5%) | 592 |
| Efficacy | ~99 Lm/W |
| Operating Temperature | -20°C to +45°C |
| Beam Angle | 38° |
| Operating Hours | >50000 |
| IP Rating | IP20 |
| IK Rating | IK08 |
Light Source Data
| Kelvins | 3000K |
| CRI | >90Ra |
Photometric Diagram
Image not available
ricoman.com
Product design and technical data may be subject to change.
