RICOMAN Lighting
CANOPUS
CANOPUS
Canopus 100W Multi Purpose Fitting 5000K Emergency
Product Data
Part Code (s)R123101
ApplicationsInterior/ Exterior
Warranty7 years
Certification(s)CE, RoHS
Physical Data
Colour FinishBlack
Dimensions (mm)H272 x L257 x W333
Luminaire FixingSurface Mounted, Suspended
Construction MaterialAluminium
Diffuser TypeTPa rated
Electrical Data
Wattage100W
Voltage RangeAC90-260V
Power Factor>0.95
Inrush Current<75A
Running CurrentDC2.65A
Dimension Diagram
Dimension Diagram
ricoman.com Product design and technical data may be subject to change.
0161 877 1399 sales@ricoman.com
Part Code: R123101
RICOMAN Lighting
Technical Data
Lumens (±5%)14559
Efficacy~148Lm/W
Operating Temperature-20°C to +40°C
Beam Angle120° - 180°
Operating Hours>70000
IP RatingIP65
IK RatingIK09
Light Source Data
Kelvins5000K
CRI>80Ra
LEDsEpistar
Photometric Diagram

Image not available

ricoman.com Product design and technical data may be subject to change.
0161 877 1399 sales@ricoman.com
