RICOMAN Lighting
Protium Max
Protium Max
Protium Max Double Downlight 50W 3000K
Product Data
Part Code (s)R093012/3K/50W
ApplicationsInterior
Warranty5 years
Certification(s)CE, RoHS UKCA
Physical Data
Colour FinishWhite
Body ColourWhite
Dimensions (mm)H133 x L330 x W175mm
LengthDouble Head
Luminaire FixingRecessed
Construction MaterialAluminium
Diffuser TypeAcrylic
Electrical Data
Wattage50W
Voltage RangeAC220-240
Power Factor>0.95
Inrush Current<60A
Running CurrentDC1200mA
Dimension Diagram
Dimension Diagram
ricoman.com Product design and technical data may be subject to change.
0161 877 1399 sales@ricoman.com
Part Code: R093012/3K/50W
RICOMAN Lighting
Technical Data
Lumens (±5%)5016
Efficacy~100 Lm/W
Operating Temperature-20°C to +45°C
Beam Angle40°
Operating Hours>50000
IP RatingIP20
IK RatingIK05
Light Source Data
Kelvins3000K
CRI>91Ra
Macadam Ellipseequal or less than 3 sdcm
L80 B5090000 hours
LEDsSingle Bin Bridgelux COB
Photometric Diagram

Image not available
