E-Pro Surface
E-Pro Surface Mounted 8W 2x2 Cells Black Finish 3000K
Product Data
| Part Code (s) | R093622/BK/3K/8W |
| Applications | Interior |
| Warranty | 5 years |
| Certification(s) | CE, RoHS, UKCA |
Physical Data
| Colour Finish | Matte Black (RAL9005) |
| Body Colour | Black |
| Dimensions (mm) | 86 x 86 x H88mm |
| Luminaire Fixing | Surface Mounted |
| Construction Material | Aluminium |
| Diffuser Type | Polycarbonate TPa Rated (Round Aperture) |
Electrical Data
| Wattage | 8W |
| Voltage Range | AC200-240V |
| Power Factor | >0.90 |
| Inrush Current | <10A |
| Running Current | 200mA |
Dimension Diagram
ricoman.com
Product design and technical data may be subject to change.
0161 877 1399
sales@ricoman.com
Part Code: R093622/BK/3K/8W
Technical Data
| Lumens (±5%) | 790 |
| Efficacy | ~99 Lm/W |
| Operating Temperature | -20°C to +45°C |
| Beam Angle | 50° |
| Operating Hours | >50000 |
| IP Rating | IP20 |
| IK Rating | IK07 |
Light Source Data
| Kelvins | 3000K |
| CRI | >90Ra |
| Macadam Ellipse | equal or less than 3 sdcm |
| L80 B50 | 90000 hours |
| LEDs | CREE 5050 |
Photometric Diagram
