RICOMAN Lighting
MODUS
MODUS
Modus 2.0 Circular Downlight 14W & 28W, 3000K & 4000K in Black Finish
Product Data
Part Code (s)R096920/BK/CTC/14-28W
ApplicationsInterior
Warranty5 years / Emergency 3years
Certification(s)CE, RoHS
Physical Data
Colour FinishBlack (RAL 9005)
Body ColourBlack
Dimensions (mm)Ø135 x H170mm
Luminaire FixingSurface Mounted
Construction MaterialAluminium
Diffuser TypeGlass
Electrical Data
Wattage14W and 28W
Voltage RangeAC220-240V
Power Factor>0.90
Inrush Current<15A
Running Current14W DC350mA / 28W DC700mA
Dimension Diagram
Dimension Diagram
ricoman.com Product design and technical data may be subject to change.
0161 877 1399 sales@ricoman.com
Part Code: R096920/BK/CTC/14-28W
RICOMAN Lighting
Technical Data
Lumens (±5%)1638
Efficacy~117Lm/W
Operating Temperature-20°C to +45°C
Beam Angle60°
Operating Hours>50000
IP RatingIP65
IK RatingIK08
Light Source Data
Kelvins3000K and 4000K
CRI>90Ra
Macadam Ellipseequal or less than 3 sdcm
L80 B5090000 hours
LEDsOsram
Photometric Diagram
