RICOMAN Lighting
R3
R3
R3 IP65 Fire Rated Tunable White Downlight
Product Data
Part Code (s)R095601/TW
ApplicationsInterior
Warranty5 years
Certification(s)CE, RoHS
Physical Data
Colour FinishWhite (Standard), Black, Chrome, Brushed Chrome, Antique Brass
Dimensions (mm)Ø85 x H63
Luminaire FixingRecessed
Construction MaterialAluminium
Diffuser TypePolycarbonate (TP(a) Rated
Electrical Data
Wattage6W
Voltage RangeAC220-240
Power Factor>0.90
Inrush Current<60A
Running CurrentDC300mA
Dimension Diagram
Dimension Diagram
ricoman.com Product design and technical data may be subject to change.
0161 877 1399 sales@ricoman.com
Part Code: R095601/TW
RICOMAN Lighting
Technical Data
Lumens (±5%)591
Efficacy~99Lm/W
Operating Temperature-20°C to +45°C
Beam Angle55°
Operating Hours>50000
IP RatingIP65
IK RatingIK08
Light Source Data
KelvinsTW
CRI>90Ra
Macadam Ellipseequal or less than 4 sdcm
L80 B5050000 hours
LEDsEpistar
Photometric Diagram

Image not available

ricoman.com Product design and technical data may be subject to change.
0161 877 1399 sales@ricoman.com
