Satellite

Architectural feature pendant LED luminaire with switchable wattage and colour temperature

  • Switchable Wattage: Integrated dip-switches allow you to toggle between four power outputs, enabling you to adjust lux levels on-site without changing the hardware.
  • Tri-Colour CCT: Features a selectable colour temperature switch (3000K, 4000K, or 5000K), ensuring the light tone perfectly matches the environment, from warm transit areas to cool task zones.
  • Emergency & Sensor Options: Fully compatible with plug-and-play microwave sensors and 3-hour emergency packs, providing smart energy savings and safety compliance with zero additional footprint.

Specification

Light Source Information

  • Direct light output
  • Ø400mm Switchable wattage 20-40W
  • Ø600mm Switchable wattage 40-60W
  • Ø800mm Switchable wattage 60-80W
  • Internal drivers supplied
  • >80 colour rendering index
  • Switchable Colour Temperatures 3000K, 4000K or 5000K
  • L70 B50 = 100,000 hours

Design

  • White or black frame
  • IP20 Rated
  • Suspended or surface Mounted
  • Dimensions of ⌀400mm or ⌀600mm or ⌀800mm

Optics

  • Glare control micro prismatic diffuser

Dimming

  • Non dimmable as standard
  • DALI, Mains, Casambi

Integral Emergency

  • Integral Emergency available

Miscellaneous

  • Standard Warranty: 5 years
  • Emergency Warranty: 3 years
  • To specify state:
  • Architectural pendant LED luminaire with direct lighting and micro prismatic diffuser. Constructed from aluminium housing,  400mm, 600mm & 800mm diameters versions of the luminaire are available. Available in switchable wattage and colour temperature – as RICOMAN’s Satellite.

Dimensions

Satellite dimensionsSatellite dimensionsSatellite dimensions

Features

  • Stylish, contemporary design
  • Glare control microprismatic diffuser
  • Switchable wattage
  • Switchable colour temperature
  • Available in three sizes: ø400mm, ø600mm, ø800mm
  • Durable aluminium construction
  • Suspended or surface mounted
  • Dimming options available
  • Emergency options available
  • Flicker-free

Configure Your Product

Part CodeDescriptionLumensWattageEfficacyColour TempColour FinishDimensions (mm)EmergencyReflectorWarrantyLDTDatasheet
R830101/WTSatellite D400mm Switchable Wattage 20-40W & Colour Temp 3000-5000K in White2000 - 20W / 4000 - 40W20W / 40W100Lm/W3000K | 4000K | 5000KWhiteD400 x 69.55 yearsLDT ↓Datasheet ↓
R830101/BKSatellite D400mm Switchable Wattage 20-40W & Colour Temp 3000-5000K in Black2000 - 20W / 4000 - 40W20W / 40W100Lm/W3000K | 4000K | 5000KBlackD400 x 69.55 yearsLDT ↓Datasheet ↓
R830201/WTSatellite D600mm Switchable Wattage 40-60W & Colour Temp 3000-5000K in White4000 - 40W / 6000 - 60W40W / 60W100Lm/W3000K | 6000K | 5000KWhiteD600 x 69.55 yearsLDT ↓Datasheet ↓
R830201/BKSatellite D600mm Switchable Wattage 40-60W & Colour Temp 3000-5000K in Black4000 - 40W / 6000 - 60W40W / 60W100Lm/W3000K | 6000K | 5000KBlackD600 x 69.55 yearsLDT ↓Datasheet ↓
R830301/WTSatellite D800mm Switchable Wattage 60-80W & Colour Temp 3000-5000K in White6000 - 60W / 8000 - 80W60W / 80W100Lm/W3000K | 6000K | 5000KWhiteD800 x 69.55 yearsLDT ↓Datasheet ↓
R830301/BKSatellite D800mm Switchable Wattage 60-80W & Colour Temp 3000-5000K in Black6001 - 60W / 8000 - 80W60W / 80W100Lm/WBlackD800 x 69.55 yearsLDT ↓Datasheet ↓

Frequently asked questions

What is the Satellite pendant and where would I use it?

Satellite is a modern architectural pendant with a robust cast aluminium body, available in three sizes from 400mm up to 800mm diameter. It can be surface mounted as standard or suspended using an optional suspension kit, so the same design can be specified across a range of ceiling conditions. This makes it a practical choice for offices, reception areas and other commercial interiors where a clean, architectural pendant is needed at different scales across a building.

What colour temperature and wattage flexibility does Satellite offer?

Satellite has switchable colour temperature between 3000K and 4000K and switchable wattage within each size, so the installer can set both on site rather than being locked into a single configuration at the point of order. This reduces the risk of specifying the wrong output for a room and allows the light level and colour to be fine tuned once the fitting is in place. It gives contractors one product that can flex to suit a change in brief late in a project.

Is Satellite suitable for spaces with occupancy-based lighting control?

Yes, Satellite can be specified with an integral microwave sensor for occupancy detection, alongside mains, DALI or Casambi dimming. This makes it a practical choice for corridors, washrooms or intermittently used areas where lighting should respond to movement rather than stay on constantly, helping reduce running costs without needing a separate control fitting.

Can Satellite be surface mounted and suspended from the same fitting?

Yes, Satellite is designed for surface mounting as standard, with suspension available as an option using a 1.5 metre suspension kit accessory. This means the same pendant can be fixed directly to the ceiling in one area and hung as a suspended feature elsewhere in the same scheme, without switching to a different product range. It gives designers and contractors one consistent look to specify across varied ceiling heights and conditions.

What control options does Satellite support?

Satellite can be specified with mains dimming, DALI dimming or Casambi wireless control, along with an integral emergency option and a microwave sensor for occupancy detection. This range means the fitting can be integrated into a standard building lighting control system or specified for areas that need automatic switching or emergency lighting compliance. Having these options within one product line simplifies scheduling for contractors working across a mixed use building.

What technical performance and warranty information is available for Satellite?

Satellite carries a colour rendering index above 80 Ra, a 90 degree beam angle and an IP20 rating, with an L70 B50 lifetime of 100,000 hours. It is backed by a 5 year warranty, with emergency versions covered for 3 years, and its Class II construction means it does not require a separate earth connection. These figures give specifiers a clear basis for comparing Satellite against other architectural pendants when preparing a technical schedule.
