Modus
IP65 protection without the bulkhead look. A circular LED downlight, surface mounted or pendant, for washrooms, hospitality and other damp commercial spaces.
- Fits the scheme: white, black or custom RAL, surface mounted or as a pendant.
- Fewer codes to specify: switch between 14W and 28W and between 3000K and 4000K on site.
- Handles damp and cleaning: IP65 and IK08 rated.
- True colours: CRI above 90 shows finishes and food as they should look.
Specification
Light Source Information
- Direct light output
- 14W & 28W switchable
- 14W delivering 1638lm
- 28W delivering 3276lm
- Efficacy up to 117lm/W (4000K)
- CRI >90 Ra
- Beam angle 60°
- 3000K or 4000K colour temperature
- L70 B50 = 100,000 hours
Electrical
- Input voltage: AC220-240V
- Power factor: >0.90
- Inrush current: <15A
- Class 1
- Drivers supplied – integral
- Cable entry from the back
- Running current: 14W DC350mA / 28W DC700mA
Design and mounting
- Aluminium body, clear glass diffuser
- White (RAL9016) or black (RAL9005) Custom RALs available.
- IP65 rated. Front only IP65 for emergency and dimming options
- IK08
- Surface mounted as standard
- Pendant option available
Dimensions
- ø135 x 170mm
Optics
- Glass diffuser – TPa rated
Compliance
- Glass diffuser – TPa rated
Controls
- Non-dimmable as standard
- DALI available (Front only IP rated)
- Integral emergency available (Front only IP rated)
Compliance
- UKCA, CE, RoHS
- Diffuser – TPa rated
Warranty
- Standard Warranty: 5 years
- Emergency Warranty: 3 years
To specify state:
- Modus 2.0 IP65 circular LED downlight, surface mounted or pendant, 14W/28W and 3000K/4000K switchable, CRI >90, 60° beam, [white/black/RAL] aluminium body, [non-dim / DALI-2 / emergency], by Ricoman
Dimensions
Features
- One fitting for wet areas and front of house
- White, black or custom RAL aluminium body: matches the interior scheme
- Surface mounted or pendant (1.5m kit): works with solid, exposed or shallow ceilings
- IP65 rated: protection against humidity and dust. Solution for washrooms and areas that are cleaned often (front only for emergency or dimming options)
- CRI >90: colours and finishes look as they should
- 14W / 28W switchable: set the output on site to suit the room
- 3000K / 4000K switchable: warm for hospitality, cool for working areas
- TPa rated diffuser
- Up to 117 lm/W (4000K): good output for the energy used
- 60° beam: even light without dark patches
- IK08 impact rated: stands up to knocks in busy spaces
- Integral driver: a simpler install with nothing extra in the ceiling
- 5 year warranty (3 years for emergency versions)
- DALI-2 dimming and integral emergency available: one product covers controls and emergency lighting
- 1.5m suspension available
Configure Your Product
| Part Code | Description | Lumens | Wattage | Efficacy | Colour Temp | Colour Finish | Dimensions (mm) | Emergency | Reflector | Warranty | LDT | Datasheet | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | R096920/WT/CTC/14-28W | Modus 2.0 Circular Downlight 14W & 28W, 3000K & 4000K in White Finish | 1638 | 14W and 28W | ~117Lm/W | 3000K and 4000K | White (RAL 9016) | Ø135 x H170mm | Non emergency | – | 5 years / Emergency 3years | LDT ↓ | Datasheet ↓ |
 | R096920/BK/CTC/14-28W | Modus 2.0 Circular Downlight 14W & 28W, 3000K & 4000K in Black Finish | 1638 | 14W and 28W | ~117Lm/W | 3000K and 4000K | Black (RAL 9005) | Ø135 x H170mm | Non emergency | – | 5 years / Emergency 3years | LDT ↓ | Datasheet ↓ |
Accessories
You may also like
Frequently asked questions
What is the Modus downlight and how can it be mounted?
Modus is a circular downlight that can be specified as surface mounted or, using the optional 1.5m pendant kit, suspended as a pendant fitting. This gives specifiers flexibility to use the same product in flush ceiling applications or dropped from a higher ceiling where a pendant look is preferred. It has a white or black aluminium body as standard. Bespoke RAL available.
What is Modus's diffuser and why does it matter?
Modus uses a glass diffuser with a TP(a) rating, a fire performance classification relevant to specifiers checking ceiling and diffuser material compliance on a project. Its IP65 rating, this makes Modus suitable for areas needing both moisture resistance and a compliant diffuser material. The glass construction also gives a different visual quality compared with plastic diffusers.
What wattage and colour temperature options does Modus offer?
Modus is available in two wattage options, 14W or 28W, and in 3000K or 4000K colour temperatures, giving flexibility to match different areas of a scheme. Optional DALI-2 dimming is available for projects requiring lighting control integration.
Is Modus suitable for damp or wet areas?
Modus carries an IP65 rating, giving it protection against dust and water jets, which suits bathrooms, kitchens, and other areas where moisture resistance is required. Its high efficacy of around 110 lm/W and CRI above 90 Ra mean it also performs well as general lighting in these spaces. Note that the DALI-2 dimming and emergency versions are non-IP rated, so the full IP65 protection applies to the standard fixed-output fitting.
How does Modus compare to Modus Max?
Modus is a smaller-scale downlight offered in 14W or 28W, suited to surface mounted or pendant installations in standard rooms. Modus Max shares the same white aluminium body and glass TP(a) diffuser concept but scales up to 70W, 100W, or 150W and is designed to be suspended by chain or rod in larger spaces. Specifiers needing higher output for larger areas should look to Modus Max, while Modus suits more typical room-scale applications.
