CARINA
A cost and energy efficient pl downlight replacement designed to reduce glare and suit a variety of applications
- Cost & Energy Efficient - Uses less power than traditional PL lamps and lasts longer, reducing electricity and maintenance costs.
- Low‑Glare, High Uniformity - Recessed design with opal diffuser and recessed light source for controlled, comfortable light in retail, office and residential fit‑outs.
- Flexible Spec Options & Reliable Performance – Multiple wattages (12W–23W) and 3000K/4000K colour temps with dimming and emergency options
Specification
Light Source Information
- Direct light output
- 12W | 15W | 18W | 23W delivering up to 2420lm
- Efficacy of up to 106lm/W
- Drivers supplied
- >85 colour rendering index
- Colour Temperature options of 3000K and 4000K
- L70 B50 = 70,000 hours | L90 B50 = 25,000 hours
- Epistar LEDs with a ≤4 step Macadam ellipse tolerance
Design
- White bezel
- IP20 rated
- Various sizes – 145mm, 160mm, 165mm and 200mm
- Cut out extension ring available to cover gaps in oversized cutouts
- IK05 impact resistant
- Ceiling recess mounted
Cutout
- 12W = ø130mm
- 15W = ø140mm
- 18W = ø165mm
- 23W = ø200mm (cut out extension ring available 250-270mm)
Optics
- Opal TP(b) rated polystyrene diffuser
- Recessed light source to control glare
Dimming
- Non dimmable as standard
- Mains, DALI 0-10V, DSI dimming available
Miscellaneous
- 3hr emergency available
- DALI Addressable emergency available
- Z10 remote control manual or advanced self-test emergency available
- Standard Warranty: 5 years
- Emergency Warranty: 3 years
- To specify state:
- Recessed LED downlighter with robust aluminium body ensuring excellent thermal control. Ideal PL downlight replacement – as RICOMAN’s Carina range.
Dimensions
Features
- Aluminium body ensuring excellent thermal control
- 12W | 15W | 18W | 23W
- 3000K | 4000K
- Cut out extension ring available on the 23W version
- CRI> 85 Ra
- Dimming options available
- Emergency options available: Standard | DALI | Remote control testing
- L70 B50 = 70,000 hours | L90 B50 = 25,000 hours
- Epistar LEDs with a ≤4 step Macadam ellipse tolerance
- Recessed light source and opaque diffuser to reduce glare
Configure Your Product
| Part Code | Description | Lumens | Wattage | Efficacy | Colour Temp | Colour Finish | Dimensions (mm) | Emergency | Reflector | Warranty | LDT | Datasheet | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | R093308 | Carina Downlight 23W 4000K | 2420 | 23W | ~105Lm/W | 4000K | White | Ø230 x H82 | Non emergency | – | 5 years | LDT ↓ | Datasheet ↓ |
| R093307 | Carina Downlight 23W 3000K | 2418 | 23W | ~105Lm/W | 3000K | White | Ø230 x H82 | Non emergency | – | 5 years | LDT ↓ | Datasheet ↓ |
| R093306 | Carina Downlight 18W 4000K | 1893 | 18W | ~105Lm/W | 4000K | White | Ø190 x H77 | Non emergency | – | 5 years | LDT ↓ | Datasheet ↓ |
| R093305 | Carina Downlight 18W 3000K | 1888 | 18W | ~105Lm/W | 3000K | White | Ø190 x H77 | Non emergency | – | 5 years | LDT ↓ | Datasheet ↓ |
| R093304 | Carina Downlight 15W 4000K | 1591 | 15W | ~105Lm/W | 4000K | White | Ø160 x H66 | Non emergency | – | 5 years | LDT ↓ | Datasheet ↓ |
| R093303 | Carina Downlight 15W 3000K | 1585 | 15W | ~105Lm/W | 3000K | White | Ø160 x H66 | Non emergency | – | 5 years | LDT ↓ | Datasheet ↓ |
| R093302 | Carina Downlight 12W 4000K | 1247 | 12W | ~100Lm/W | 4000K | White | Ø145 x H56 | Non emergency | – | 5 years | LDT ↓ | Datasheet ↓ |
| R093301 | Carina Downlight 12W 3000K | 1207 | 12W | ~100Lm/W | 3000K | White | Ø145 x H56 | Non emergency | – | 5 years | LDT ↓ | Datasheet ↓ |
Accessories
You may also like
Frequently asked questions
Can the Carina downlight replace older PL lamp downlights?
Yes. Carina is designed as a cost and energy efficient replacement for older PL lamp downlights, giving contractors an LED upgrade path for existing compact fluorescent fittings. It is designed to reduce glare compared with older lamp technology while delivering good thermal control. This makes it a practical retrofit option for wholesalers supplying replacement stock for refurbishment work.
What size and wattage range does Carina cover?
Carina is available in four sizes with wattages of 12W, 15W, 18W, or 23W, and in two colour temperatures, 3000K or 4000K. This range allows one product family to suit a variety of room sizes and applications on the same project. An extension ring accessory is available for the largest 23W cutout size.
Does Carina support dimming or emergency lighting?
Carina can be specified with dimming options, including mains, DALI, 0-10V, or DSI dimming, as well as an emergency lighting version. This gives specifiers the flexibility to use the same downlight family in both standard and emergency circuits, or where lighting control is required. These options are selected at order stage alongside size and colour temperature.
How does Carina manage heat and glare?
Carina is built to deliver good thermal control alongside reduced glare compared with the PL lamp fittings it is designed to replace. Good thermal management supports the stated operating life and lumen maintenance of the fitting over time. This combination of thermal control and glare reduction is presented as a core benefit of upgrading from older lamp-based downlights.
How does Carina compare to Neptune for PL lamp replacement work?
Carina and Neptune are both designed to replace older PL lamp downlights, but Carina is rated IP20 and focuses on dimming and emergency lighting options across its four sizes, while Neptune is rated IP65 and offers a choice of four magnetic reflector finishes. Carina is generally the better fit where lighting control or emergency provision is the priority, while Neptune suits areas needing moisture resistance or a specific decorative reflector finish. Both are supplied with a 5 year warranty.
